Javac Edge Hi Flow Core Removal Tool – JAV-1600

The Ultimate Hi-Flow Core Removal Tool is a professional-grade, vacuum and pressure-rated valve core removal accessory designed for HVAC/R service, refrigerant recovery, and system evacuation. By removing restrictive valve cores, it provides true full-flow system access, significantly increasing both recovery and evacuation speed as well as the achievable depth of vacuum. It also allows connection to a vacuum gauge as close as possible to the unit being evacuated. This tool will improve service time on any system that relies on a Schrader valve for refrigerant access.

Product Features :-

• Full-flow valve core removal – Eliminates core restriction for maximum flow, faster recovery or evacuation
• Deep-vacuum rated – Maintains leak-free performance under vacuum conditions.
• High-pressure rated – Safe for charging and use with high pressure refrigerants (e.g. R410a)
• Magnetic base / secure handling – Prevents lost valve cores during service
• Core-retention removal mechanism – Securely grips and extracts cores to avoid loss
• Side-port connection – Enables gauges or hoses for evacuation, charging, or testing
• No tools required – Hand tighten only
• Two sizes in one tool – 1/4” and 5/16”
• Refrigerant Ready – Compatible with A1, HFC/HFO, low GWP A2L and A3 refrigerants
• Maximum Working Pressure 800 psi (approx. 55bar) matching higher pressure refrigerant system requirements (R410A)
